HOUSING WAFER TERMINAL
3.96mm Terminal / Housing / Wafer
3961SB-XXTW-L

Current Rating::
7A AC,DC

Voltage Rating::
250V AC,DC

Temperature Range::
- 25°C to +85°C

Contact Resistance::
10m ohm. Max

Insulation Resistance::
1000M ohm. Min

Withstanding Voltage::
1500V AC/minute
