PLASTIC PARTS FOR PCB
02 | LED SUPPORT
LEMA-2F
● TITLE：LIGHT PIPE
● PART NO：LEMA - 2F (see datasheet for measures)
MATERIAL ：PC(UL)
FLAME CLASS ：UL94V - 2
COLOR ：TRANSPARENT
UNIT：mm
Application：Work with M4 nut, and guide the LED light on case panel, and make light soften, smooth, and waterproof, convenient.
Note：Work with TF - 807 silicon washer and M - 4 plastic screw.
※ IP68 certified
THE PACKAGING IS INNER / OUTER BAG PACKAGING. IT CONTAINS:
LEMA - 2*1000 PACKAGE, TF - 807*1000 PACKAG, EM - 4*1000 PACKAGE
ABOVE PARTS CAN ALSO BE PURCHASED SEPARATELY.
